Install Wedge Anchors
From Install Outdoor Handrail · Step 5 of 8 · Video by Family DIY tv
Showing 3:24–4:36 of the source video.
What happens in this clip
Insert the wedge anchors into the cleaned holes. The expansion mechanism should be on the bottom. Lightly tap each anchor with a hammer until it is mostly seated, leaving some threads exposed above the concrete surface. Ensure the anchors are straight and aligned, not tilted, to allow the post to sit flat. While the design allows for some wiggle room, aim for precise placement.
Goal: Properly seat the wedge anchors in the concrete, ready for post attachment.
What's used
Tools
- Hammer Unspecified
- Wedge Anchors Red Head TruBolt
About the full video
This project details the installation of a modular privacy wall system, specifically using HOFT posts and either wood or composite boards. It covers attaching mounting plates, anchoring posts into concrete, and finally installing the wooden boards, with tips on ensuring stability and aesthetics.
Step 5 of 8: Install Concrete Anchors
Depending on the type of anchor (e.g., expansion anchors, wedge anchors, or screw anchors), follow the specific installation method. For expansion anchors, tap them into the hole and then tighten the bolt or nut to expand the anchor. For screw anchors, drive them into the hole using the appropriate tool. Ensure anchors are flush with or slightly below the concrete surface.
Other videos for this step
Install Outdoor Handrail
This project outlines the steps for installing a surface mount handrail on outdoor concrete steps. It covers selecting the appropriate handrail and hardware, preparing the concrete surface, marking and drilling holes, and securely mounting the handrail.
